Application:
It is suitable for product in round shape for single, double or located labeling. It can be a justed for cone-shaped prouducts. It can be used individually or attached to assemble line. It is widly used with bear bottle, beverage bottle, shampoo and comestic.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packing Exambers:
Good labeling performance, label is flat with wrinkle.
Inteligent control, automatic photoelectric tracking with la be-ing, no objects no labeling.
Easy adjustment, labeling speed and conveying speed and bottle allocation speed can be adjusted steplessly.
Simple structure in linear type ,easy in installation and maintation.
Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
High pressure double crank to control the die opening and closing.
Running in a high automatization and intellectualization,no pollution
Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .
NAME | Technical parameters |
Model | LD-TB130 |
labeling range | L<300mm,H<120mm |
Labeling speed | 60 bottle/min |
Labeling accurancy | ±1.5mm |
Size of main frame | L1900*W800*1450(mm) |
Working voltage | 220V |
Electricity power | 420W |
Weight | 250KG |
Packing Dimension | 2100(L)*1150(W)*1450(H)mm |
