Application:
suitable for packaging various kinds of regular objects like frozen meat, frozen fish, frozen seafood, chicken, beef, noodles, moon-cakes, drugs, daily applications, industrial parts,paper boxes,tray etc.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packing Exambers:
Dual frequency conversion control, Bag length can be set and cut in one step,saving time and film.
Interface features easy and quick setting and operation
Self failure diagnosis, clear failure display
High sensitivity photoelectric eye color tracing, numerical input of cutting sealing position for extra accuracy.
Temperature independent PID control, more suitable for packaging different materials
Positioned stop function, without sticking knife or wasting film.
Simple driving system, reliable working, convenient maintenance.
All control is realized through software,easy for function adjusting and technical upgrade.
Model | LP-350 | LP-400 | LP-450 | LP-600 | LP-700 |
Film Width | Max.350mm | Max.400mm | Max.450mm | Max.600mm | Max.700mm |
Bag Length | 65-330mm | 150-400mm | 150-450mm | 160-500mm | 180-600mm |
Bag Width | 50-160mm | 50-180mm | 50-180mm | 100-280mm | 100-330mm |
Products High | Max.60mm | Max.65mm | Max.75mm | Max.110mm | Max.110mm |
Film Roll Diameter | Max.320mm | Max.320mm | Max.320mm | Max.320mm | Max.320mm |
Packing Speed | 40-180bag/min | 30-150bag/min | 30-150bag/min | 20-150bag/min | 20-130bag/min |
Power | 220V 50/60Hz | 220V 50/60Hz | 220V 50/60Hz | 220V 50/60Hz | 220V 50/60Hz |
2.6KW | 2.8KW | 2.8KW | 2.8KW | 2.8KW | |
Machine Size | 4030*770*1420 | 4030*770*1420 | 4030*820*1420 | 4030*970*1500 | 4030*1070*1500 |
(L*W*H)mm | |||||
Machine Weight | About 580kg | About 600kg | About 650kg | About 680kg | About 720kg |
Optional Devices | 1.Lateral feed device, 2.Straight feed device, 3.Belt material conveyor, 4.End sealing auxiliary conveyor, 5.Auxiliary material feeding device, 6.Materia cut prevent device, 7.Perforating device, 8.Angle folding device, 9.Date Printer, 10.Labelling machine |
Después de recibir su consulta, le enviaremos la cotización lo antes posible.
