Application:
Suitable for packing regular objects such as frozen meat, frozen fish, frozen seafood, biscuits, bread, instant noodles, drugs, daily appliances, industrials parts, paper boxes, plates, vegetable, fruit, etc.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packing Exambers:
Three servo motor control, Bag length can be set and cut in one step,saving time and film.
Interface features easy and quick setting and operation
Self failure diagnosis, clear failure display
High sensitivity photoelectric eye color tracing, numerical input of cutting sealing position for extra accuracy.
Temperature independent PID control, more suitable for packaging different materials
Positioned stop function, without sticking knife or wasting film.
Simple driving system, reliable working, convenient maintenance.
All control is realized through software,easy for function adjusting and technical upgrade.
Type | LP-450W | LP-600W |
Film width | Max.450mm | Max.600mm |
Bag length | 120-450mm | 120-450mm |
Bag width | 50-160mm | 50-200mm |
Product height | 10-80mm | 10-80mm |
Film roll diameter | Max.320mm | Max.320mm |
Packaging rate | 20-80 bag/min | 20-80 bag/min |
Power | 220V 50/60Hz,3.2kw | 220V 50/60Hz 3.6kw |
Machine size | (L)4380*(W)870*(H)1500mm | (L)3990*(W)970*(H)1500mm |
Machine quality | 960kg | 1160kg |
Remarks | Reciprocation end sealing system, with angle folding device | |
Film material | OPP、PE、PVC、OPP/CPP、PT/PE、KOP/ CPP/ Aluminum Coating Film/ Aluminum Film |
Después de recibir su consulta, le enviaremos la cotización lo antes posible.
